Gardenline LT26 - Assembly and Preparation; Parts Identification

S U A
1800 909 909
www.globalpowerbrands.com email: help@globalpowerbrands.com
AFTER SALES SUPPORT
43670
9
1. Cutting line spool
and assembly
2. Cut off knife
3. Safety guard
4. Handle
5a. Upper shaft
5b. Lower shaft
6. Recoil starter
7. Ignition On/Off switch
8. Fuel tank
9. Throttle trigger
10. Primer
11. Spark plug
12. Filter cover
13. Safety lever
14. Choke lever (red)
15. Handle locking screws x 2
16. Spark plug wrench
17. Carry strap
18. Bump knob
19. Hex key
20. Throttle lock button
21. Shaft locking knob
Parts List
62
15
1
18
21
11
12
14
13
7
3
5a
4
9
5b
8
3
Note. Before operating ensure
that the protective cover is
removed from the cut-off knife.
10
7
20
16
17
19
