2. PARTS DESCRIPTION (Fig A .)
1. Throttle Trigger 2. Lock-out 3. On/Off Ignition Switch 4. Top Assist Handle
5. Starter Handle 6. Spark Plug Wire / Spark
Plug
7. Air Cleaner Cover 8. Choke Lever
09. Fuel Tank 10. Fuel Cap 11. Harness 12. Primer Bulb
13. Control Handle 14. Operating Tube 15. Throttle Linkage 16. Flex Tube
17. Hose Clamp 18. Muffler Cover 19. Spark Arrester Screen 20. Vented Back Pad
21. Intermediate Tube 22. 56mm Nozzle 23. 45mm concentrator
Nozzle
24. Curved Nozzle
User Guide
1. Normal use - Leaf Blower
