6.3 CARBURETOR ADJUSTMENT
The carburetor was pre-set at the factory for optimum performance. If further adjustments are necessary take your
blower to a qualified service dealer.
6.4 SPARK PLUG
1. To remove spark plug(B)(Fig.22)for cleaning or
replacement: make sure engine is off, spark plug
is cool, then grasp spark plug boot firmly and
remove from spark plug. Remove spark plug with
correct spark plug tool. Inspect, clean or
replace as needed.
2. Spark plug gap =.025 in.(.635mm)(Fig.22).
3. Torque to 105 to 130 inch pounds (12 to 15 Nm).
Connect spark plug boot. Fig.22
7. TECHNICAL DATA
Model GSTD26ROOF
Air velocity 280km/h
Air volume 8m
3
/min
Engine displacement 26 cm
3
Fuel tank capacity 500 ml
Fuel type unleaded
Fuel mixture 30:1
rated engine power 0.7kW /7500 min
-1
Idling speed 3500 min
-1
Max engine speed 9000 min
-1
Sound pressure level :
- Idling: 82,1 dB(A)
- Racing: 93,8 dB(A)
- Average: 93,18 dB(A)
- Uncertainly K=3 dB(A)
Sound power level:
- Idling: 92,31 dB(A)
- Racing: 105,34 dB(A)
- Average: 105,34 dB(A)
- Uncertainly K=3 dB(A)
Sound power level according to 2000/14/EC:
- Measured: 106,4 dB(A)
- Guaranteed:107 dB(A)
Vibration:
- Idling: 2,241 m/s
2
- Racing: 1,100 m/s
2
- Average: 1,325 m/s
2
- Uncertainly K=1,5 m/s
2
Dry weight 5.7 Kg
year of construction BJ2016
