16
4. Standing behind the unit, push & hold the brake control handle against the upper handle (fig. 41).
5. Press the starter button on the panel (fig. 42). Release it once the motor starts runnning. Turn the chocke
lever to
Release the brake control handle to stop engine and blade.
6. After having finsihed to mow, please turn the fuel lock to the ” “ position (fig. 43).
Figure 39 Figure 40 Figure 41
Figure 42 Figure 43
7.3 OPERATION PROCEDURE
During operation, tightly hold the brake handle with both hands.
Note: During operation, when the brake handle is released, the engine and thus the lawnmower stops to
operate.
7.3.1 front wheel fixation on GBD-51R (DYM162601)
Switch the locking handle #23 to “ “position to allow the steering of the front wheel #25 (fig.44).
Switch the locking handle to” ’position to fix the wheel in a straight position (fig. 45).
Figure 44 Figure 45
WARNING: In order to avoid any unintentional start-ups of the lawn mower, it comes equipped with an
engine brake which must be pulled back before the engine can be started. To mow, hold the lever in the
working position. When the engine control lever is released, it must return to its initial position, at which point
the engine automatically switches off and the blade stops immediately. Before you start to mow, check the
starter button
