Gardol GBD-51REV User Manual

8
4. TECHNICAL DATA
model GBD-46R
(DYM1676CE-3)
GBD-51R
(DYM162601)
GBD-46REV
(DYM1676SED-3)
GBD-51REV
(DYM1678SD-3)
engine type DG600 DG600 DG600E
(DYM1P70FE)
DG600E
(DYM1P70FE)
engine build 4-stroke, overhead valve, single cylinder
engine displacement (bore &
stroke)
173 cm
3
(70 * 45 mm)
nominal power 3.6 kW
blade length 460 mm 510 mm 460 mm 510 mm
max. torque 9.5 Nm at 2700 min
-1
cooling system forced air
lubrication systems forced splash
starting method recoil starter electric & recoil starter
electric starter battery
▬
12 V, 4.5 Ah • type FM1545
charger for electric starter battery
▬
Input: 100 – 240 V AC, 50 – 60
Hz, 0.32 A
Output: 13.8 V DC, 0.5 A
Type: HYCH0131380500G
ignition system TCI
PTO shaft rotation counter-clockwise
spark plug gap 0.7 - 0.8 mm
rated speed 2800 min
-1
valve clearance (cold) 0.1 - 0.15 mm
fuel tank capacity 1.8 l
motor oil quantity needed 0.4 l
grass catcher capacity 60 l
net weight 36.0 kg 39.2 kg 38.0 kg 42.3 kg
height adjustment 25 - 75mm, 7
positions
25 – 75 mm, 6
positions
25 - 75mm, 7
positions
25 – 75 mm, 7
positions
guaranteed sound pressure level
at the operator’s position
(according to EN ISO 5395-1
annex F & EN ISO 5395-2, EN ISO
4871
83.7 dB(A)
K = 3 dB(A)
83 dB(A)
K = 3 dB(A)
83.7 dB(A)
K = 3 dB(A)
81.9 dB(A)
K = 3 dB(A)
measured sound power level 93.9 dB(A)
K = 1.81 dB(A)
96.4 dB(A)
K = 1.80 dB(A)
93.9 dB(A)
K = 1.81 dB(A)
95.0 dB(A)
K = 2.88 dB(A)
guaranteed sound power level
(according to 2000/14/EC)
96 dB(A) 96 dB(A) 96 dB(A) 98 dB(A)
vibration (according to EN ISO
5395-1 annex G & EN ISO 5395-
2)
5.37 m/s²
K = 1.5 m/s²
11.40 m/s²
K = 1.5 m/s²
5.37 m/s²
K = 1.5 m/s²
3.37 m/s²
K = 1.5 m/s²
