MDE-4645B Model 52 Pressure Regulator Valve Installation/Parts Manual · August 2019 Page 13
Model 52 Pressure Regulator Valve Parts List Parts
Model 52 Pressure Regulator Valve Parts List
Note: For the complete Model 52 Valve Assembly, order Gasboy Part Number 048577PG8.
Note: Gasboy has redesigned the Model 52 Pressure Regulator Valve eliminating the need for
a “cold weather” version of the valve. A new Diaphragm and standardized diesel
strainer are now included with the standard valve making it appropriate for warm and
cold weather conditions.
Item Part Number Description
1 026768 Square Ring
2 014273 Square Ring
3 014274 Valve Cover
4 014319 Pressure Relief Valve Assembly
5 063312 Suction Screen Complete, Gas
063313 Suction Screen Complete, Diesel
6 014262 Pilot Valve Spring
7 014318 Gasket
8 014277 Valve Spring
9 063203 Suction Strainer Cap
10 014267 Safety Shear Section
11 014317 Diaphragm (for Model 52)
12 014276 Poppet Complete
13 014280 Poppet Assembly
14 014263 Valve Actuator
15 014320 Valve Body Assembly, Model 52
Note: When replacing this assembly on a Model 52, the Model 52
Diaphragm is also required.
16 014282 Diaphragm Cover
17 003433 Screen Adapter Coupling
18 K43625 1/4-20 X 3/4" Long Hex Head Cap Screw
19 K01914-75 7/16-14 X 1-1/4" Long Hex Head Cap Screw
20 K08674
90
°
Street Elbow
21 K02278 1/8” Plug Pipe
22 K78953-30 1/4” Plug, Protective Closure
