GASLAND BE Series - User Manual

Other manuals for GASLAND BE Series

Installation Instructions24 pages

Questions and Answers

M
Mark ToddAug 18, 2025
How to fix GASLAND BE if water is not hot enough?
- B
  Brandy CarpenterAug 18, 2025
  If the water from your GASLAND Water Heater isn't hot enough, try these steps: First, adjust the gas and water knobs to increase the flame and reduce water flow. If that doesn't work, consider reducing the water supply or cycling water between the appliance and a reservoir to reach your desired temperature. Ensure the gas valve is fully open to maximize gas volume. Also, clean the gas route system. Note that efficiency decreases at altitudes above 2,000 feet, and carbon buildup in the heat exchanger can also cause this issue; clean the heat exchanger if the flame is yellow.
M
Michelle SilvaAug 20, 2025
What to do if GASLAND BE clicks but doesn't start?
- P
  Patricia NormanAug 21, 2025
  If your GASLAND Water Heater clicks but doesn't start, it could be due to several reasons. Make sure you're using a 20lb propane cylinder. Check that the water pressure is sufficient, between 3.6-110 PSI. Also, inspect and clean the gas inlet filter for any blockages. Finally, the ignition pins might be misaligned or aging; try bending the ignition pin back by 3-4mm to heat the burner, or replace the ignition pin if needed.
M
Matthew JacksonAug 23, 2025
How to fix GASLAND BE with no clicks at start-up?
- Z
  Zachary ScottAug 23, 2025
  If your GASLAND Water Heater isn't working and there are no clicking sounds at start-up, check the following: Ensure the water inlet and outlet connections are correctly installed. Replace the batteries, making sure they're fresh and aligned with the correct polarity. Inspect the wires inside by taking off the front panel and reconnecting any that have disconnected during shipping. Clean up any blockage of the vent pipe. For issues related to the gas and water valve assembly, contact GASLAND for a troubleshooting guide. If the ignition controller is faulty, repair or replace it.
L
Lisa AlvarezAug 25, 2025
Why is the water from my GASLAND Water Heater too hot?
- A
  Anna CrawfordAug 26, 2025
  If the water from your GASLAND Water Heater is too hot, start by adjusting the gas and water knobs to reduce the flame and increase water flow. Check for blockages in the water route system by cleaning the water screen on the water inlet pipe and shower head. If the water pressure is too low, boost it with a water pump or adjust the water flow rate screw at the water inlet pipe. Regulate the pressure relief valve to reduce the overall gas supply. If these steps don't resolve the issue, consider replacing the thermostat.
M
Meghan DavisAug 27, 2025
Why does my GASLAND BE shut down shortly after starting?
- N
  Noah LittleAug 27, 2025
  If your GASLAND Water Heater shuts down soon after starting, consider these potential solutions: Try replacing the batteries with new ones. Inspect the ignition pin wire; disconnect it, cut off about 0.2-0.3 inch, and reconnect it. If the induction pin is aging, replace it. The ignition controller might also be malfunctioning, so consider replacing it. Lastly, protect the appliance from direct wind, as high winds can extinguish the flame.
J
Jennifer JohnsAug 30, 2025
What to do if my GASLAND BE experiences deflagration?
- A
  Andrew MayAug 30, 2025
  If you're experiencing deflagration with your GASLAND Water Heater, try the following: Regulate the pressure relief valve to reduce the overall gas supply. Repeat opening and closing the gas knob several times. Replace the batteries with new ones.
M
Mark GrantSep 1, 2025
How to fix a leaking water inlet/outlet pipe on a GASLAND Water Heater?
- A
  Anthony CooperSep 1, 2025
  If the water inlet or outlet pipe of your GASLAND Water Heater is leaking, try wrapping a few turns of Teflon tape around the water pipe. If the gas and water valve assembly is damaged, contact GASLAND for a troubleshooting guide.
W
whitegregorySep 3, 2025
What causes returned fire in GASLAND BE Water Heater?
- Q
  qrobertsSep 4, 2025
  If your GASLAND Water Heater is experiencing returned fire, check if the gas rubber pipe twists. You can also boost water pressure by using a water pump or adjusting the water flow rate screw at the inlet water pipe.
J
Jeffrey StewartSep 5, 2025
Why is my GASLAND Water Heater leaking inside?
- G
  garzajesseSep 6, 2025
  If your GASLAND Water Heater is leaking inside, take apart the screws of the valve assembly and adjust or replace the seal. If the gas and water valve assembly is damaged, contact GASLAND for a troubleshooting guide. If the heat exchanger is damaged by freezing, repair or replace it, referring to the "Freezing protection measures" section for freeze damage tips.
C
christina76Sep 8, 2025
How to stop a GASLAND Water Heater shower hose/head from leaking?
- D
  Dalton RoweSep 8, 2025
  If the shower hose or head of your GASLAND Water Heater is leaking, ensure the supplied rubber gasket is inserted at the shower hose connection. Try reducing the water supply. Also, avoid constantly keeping the switch in the "OFF" position when using.

Summary

Safety Warnings and Hazards

Fire, Explosion, and Gas Leak Prevention

Instructions for handling gas leaks to prevent fire or explosion.

Hot Water Burn and Carbon Monoxide Risks

Dangers of severe burns from hot water and carbon monoxide poisoning.

General Safety Guidelines and Definitions

Installation and Flammable Material Safety

Proper Outdoor Installation Safety

Ensuring safe outdoor installation and adequate air supply.

Flammable Liquids Storage Precautions

Avoid storing flammable liquids near the appliance due to fire risk.

Flammable Vapor and Propane Gas Safety

Flammable Vapor Explosion Hazard

Risk of explosion and fire from flammable vapors near the appliance.

Propane Gas Leak Detection Methods

Detecting propane leaks using odorants, leak detectors, and soapy water.

Propane Use and Gas Leak Testing

Propane Usage Cautions and California Notice

Cautions on propane use and California Proposition 65 warning.

Gas Leak Testing Procedure

Instructions for leak testing using soapy water, avoiding open flames.

Gas Leak Testing and Actions

Performing Gas Leak Tests

Applying soapy water to connections to detect gas leaks.

Actions for Suspected Gas Leaks

Immediate actions if a gas leak is present or suspected.

Appliance Purpose and Additional Warnings

Intended Use for Recreational Purposes

Describes the appliance's use for recreational showers and its features.

Important Operational Warnings

Warnings about hot surfaces, non-potable water, and outdoor use.

Product Features and Design

Key Appliance Features Explained

Details automatic ignition, auto cut-off, overheating, and anti-dry protection.

Outdoor Recreational Applications

Illustrates various outdoor activities the appliance is suitable for.

Package Contents and Model Comparison

Included Parts and Accessories

Lists essential parts and accessories included with the gas water heater.

Accessory Chart by Series

Compares included accessories across different Gasland water heater series.

Product Dimensions

Appliance Physical Dimensions

Provides length, width, height, and depth measurements for various models.

Construction and Components Overview

Identification of Appliance Parts

Diagram and list of all major parts of the gas water heater.

Installation Dimensions and Electrical Wiring

Mounting Hole Dimensions

Illustrates fixing hole dimensions for appliance mounting.

Electrical Wiring Diagram and Caution

Schematic showing connections for battery, ignition, and controls.

Installation Instructions and Precautions

Replacement Parts Availability

Information on obtaining spare parts for the water heater.

General Installation Precautions

Safety guidelines for keeping flammable materials away and ensuring upright installation.

Gas Connection and Regulator Setup

LP Gas Cylinder Specifications

Specifications for approved LP gas supply cylinders.

Gas Hose and Regulator Connection

Details on connecting the gas regulator and checking for leaks.

Appliance Setup and Powering

Water Fitting Gasket Installation

Ensuring proper gasket placement in all water fittings before connection.

Powering the Water Pump with Battery

Instructions for connecting the water pump to a 12V DC battery.

Battery Compartment Installation

Steps for installing 'D' size batteries into the appliance.

Gas Connection Procedure

Connecting Gas Regulator to Cylinder

Connecting the gas regulator to the LP cylinder and ensuring proper tightness.

Hose Inspection and Gas Leak Testing

Importance of inspecting hoses and performing leak tests after connecting gas.

Water Outlet and Pump Connections

Connecting the Shower Kit and Inlet

How to connect the shower kit and water inlet pipe.

Water Pump and Hose Configurations

Illustrations of various water pump and hose connection configurations.

Appliance Operation and Starting

Initial Startup Procedure

Step-by-step guide to turning on the water supply and gas.

Control Knob Functions Explained

Diagrams showing how to adjust gas and water flow using control knobs.

Operation, Adjustment, and Maintenance

Adjusting Water Temperature Settings

How to adjust the outgoing water temperature using control knobs.

Routine Care and Periodic Maintenance

Recommendations for periodic inspection and annual maintenance by qualified personnel.

Maintenance Checks and Safety Precautions

Burner Flame and Combustion Check

Checking burner flame color for proper combustion and ventilation.

Filter Cleaning and Surface Care

Instructions for cleaning air intake, water filters, and the appliance surface.

Critical Operational Safety Dangers

Dangers related to hot water disconnection, scalds, and lack of maintenance.

Storage and Freezing Protection

Safe Gas Cylinder Storage Practices

Safe practices for storing LP gas cylinders when the appliance is not in use.

Preventing Freezing Damage

Procedures to drain the appliance to prevent damage from freezing temperatures.

Safe Storage Procedures

Draining the Appliance for Storage

Step-by-step visual guide for draining and storing the appliance safely.

Cleaning and Service Information

Monthly Water Filter Screen Cleaning

Monthly procedure for cleaning the water inlet filter screen.

Contacting Support for Repairs

Information on how to get assistance, repairs, or spare parts.

Troubleshooting Common Issues

Appliance Startup and Temperature Problems

Solutions for no clicks, audible clicks, and water temperature issues.

Troubleshooting Leaks, Fires, and Pumps

Leak, Fire, and Deflagration Solutions

Solutions for leaks, returned fire, and deflagration.

Water Pump Performance Issues

Diagnosing and fixing issues with the water pump not working or making noise.

Warranty Information and Coverage

Limited Warranty Terms and Periods

Details on warranty period for heat exchanger, parts, and accessories.

Warranty Exclusions and Owner Costs

Conditions that void the warranty and owner's cost responsibilities.

Warranty Void Conditions and Shipping

Factors Invalidating Warranty Coverage

List of actions like abuse, misuse, or improper maintenance that void the warranty.

Warranty Shipping and Return Procedures

Guidelines for warranty-related shipping costs and obtaining RGA numbers.

GASLAND BE Series Specifications

General

Brand	GASLAND
Model	BE Series
Category	Water Heater
Language	English
