P.9
No.1
No.2
No.3
No.4
機頭方向
Nose Direction
將平台固定在機身的套環上(注意機頭方向)。
機身製作
機身製作
若採用上插的接收機時，請將接收機固定於平台下，以免艙罩無法蓋上。
Main Frame Assembly
Insert the System Platform onto the main frame (attention on nose direction).
Note: when using a receiver with top cable connection instead of side cable connection.
Install the receiver on the main frame (top frame) and not on the platform as the canopy
will not have enough space.
Main Frame Assembly
To Next Page
