G A UI
T AI SHIH HOBB Y CORPOR A TION
G A UI
T AI SHIH HOBB Y CORPOR A TION
P.8
RX
S
+
-
No.1(ESC)
No.2(ESC)
No.3(ESC)
No.4(ESC)
AILE (3-wire plug)
ELEV (red)
THRO (orange)
RUDD (yellow)
GAIN/GEAR (green)
M2 x 3.2
Post
組合平台，並將GU-344貼上防震泡棉固定在平台上。
機身製作
機身製作
GU-344與接收機及四個動力艙的接法如下。
平台
Main Frame Assembly
Assemble the system platform for Stabilizer & Receiver (for GU-344, please use
anti-vibration sponge provided)
Connect the ESC cables to the GU-344 & Receiver to GU-344 (see drawing).
Main Frame Assembly
anti-vibration
sponge
system platform
To Next Page
