O3 x 8
M2 x 5
PM2 x 3.5 x 22
O3 x 8
將內部套環凸點鑲入孔內並鎖緊。(注意：定位點在下方)
上方也同樣鎖緊，並將六支鋁柱固定至機身。
機身製作
定位點
機身製作
Main Frame Assembly
Start with Bottom side of Main Frame. Insert pivot point of Inside Boom Holder into pivot hole
and lock in place with screw (O3 x 8). (Attention: Position Indicator is on bottom).
Put on Top of Main Frame. Insert the 4 pivot points into the 4 pivot hole on Top Main Frame
and lock in place with screws (O3 x 8 ). Insert the 6 aluminum posts (PM2 x 3.5 x 22) and
lock in place with screws (M2 x 5).
Main Frame Assembly
Position Indicator
To Next Page
