1. Meter Functions
Function/
Range
Selector
Switch
Zero
Ohms
Adjust-
ment
Figure 1
Mirror
Needle
Analog
Scale
Battery/
Fuse
Cover
Zero
Adjust
Screw
Input Jacks
1.0 Meter Functions
1.0 Meter Functions
2.0 Specifications
2.1 For Your Safety
3.0 Operating Suggestions
3.1 Preliminary Adjustments
3.2 Internal Battery Condition
4.0 DC Voltage Measurement
4.1 Automotive Batteries
4.2 Alternators and Generators
4.3 Household Batteries
5.0 DC Milliamp Measurement
6.0 AC Voltage Measurement
6.1 Wall Receptacles
6.2 Appliance Receptacles
6.3 Circuit Breaker Panels
7.0 Resistance/Continuity Measurement
7.1 Extension Cords
7.2 Appliance Cords
7.3 Fuses
7.4 Switches
7.5 Heating Elements
7.6 Thermostats
8.0 Decibel Measurement
9.0 Battery and Fuse Replacement
1
Table of Contents
