12
To clean the Foam Filter:
1. Remove the foam filter from the gray filter assembly by grasping handle and lifting upward and out of the dust
cup.
2. Grasp lint trap cone and turn to remove.
3. Lift filter from cone and wash. Squeeze excess water from filter. Lint trap cone may also be washed. Do not
submerge gray filter assembly – wipe only with a damp cloth.
4. When all parts are completely dry, replace filter in cone and turn to lock cone in place.
NOTE: Foam filter will be about 1/16” above ring at large end of lint trap cone.
Gray Filter
Assembly
Use GE brand replacement filter, 61483.
Lint Trap
Cone
Foam
Filter
FOR INSTRUCTIONS ON HOW TO REMOVE THE CYCLONIC DUST CUP FROM THE CLEANER BODY, REFER TO
PAGE 12.
Emptying the Cyclonic Dust Cup:
It is clearly visible when the dust compartment is full and needs emptying. Remove dust cup from cleaner body
and dump debris in a waste container.
Reinstalling the Cyclonic Dust Cup:
To mount gray filter assembly into cleaner body, make certain gray filter assembly is fully seated in top of dust cup.
Replace dust cup by aligning front of the bottom of dust cup into groove on cleaner. Pivot dust cup up against
cleaner and rotate the dust cup latch to the right to secure.
CAUTION: The dust cup can be washed in warm water, if desired, but strong detergents should not be used. Dry
thoroughly before using again. Do not submerge gray filter assembly, wipe only with a damp cloth.
