GE 14 Use And Installation Guide

15
e. Attach the
handle to the right
edge of the door
with screws at top
and bottom, using
bottom holes
vacated by
removal of the
door stop screws.
2. Transfer the door stop.
• Move the metal door stop from the right end
to the left end. Use a Torxdriver.
• Move any screws from the left end to the
right end.
When reinstalling the fresh food door handle…
a. Attach the handle to the right side of the door
with screws at the top and under the handle plug.
b. Reinstall the handle plug.
3. Transfer the freezer door handle to
the right.
a. Remove the screw holding the handle to the
top of the door and the two screws holding the
handle to the bottom of the door.
b. Remove the handle.
c. Remove the screw from the right top edge of
the door and insert it into the handle screw hole
on the left side.
d. Transfer the door stop as shown at left.
TOP
BOTTOM
REHANG FRESH FOOD DOOR.
a. Lower the bottom
socket of the fresh
food door onto the
pin on the bottom
hinge. Be sure the
plastic washer is in
place on the pin.
b. Insert the pin on
the center hinge into
the socket in the top
of the door. NOTE:
The center hinge must
be turned over as
shown when mounted
on the left side.
c. Tilt the door toward
the cabinet. As the
door is brought into
position, slide the hinge under the head of the
screw which earlier had been partly driven into
the outermost hole. Insert the remaining screw,
then tighten both screws securely.
5
Plastic Washer
Plastic Washer
Hinge
Pin
Hinge
Pin
LEFT SIDE
RIGHT SIDE
Door Stop

GE 14 Specifications

General

Brand	GE
Category	Refrigerator
Type	Top Freezer
Voltage	120 V
Color	White
Total Capacity	14 cu ft
