GE 14 Use And Installation Guide

REHANG THE FREEZER DOOR.
a. Lower the
bottom socket of
the freezer door
onto the center
hinge pin. Be
sure the washer
is in place on
the pin.
b. Tilt the door
toward the
cabinet, lifting
the top hinge so
the pin fits into
the socket on
the top of the door.
c. Before tightening the top hinge screws, make
sure the top of the door is level with the cabinet
top and the space between the doors is equal
across the entire front. Do not overtighten these
screws––tighten them until they are just snug,
then turn them in another one-half turn.
6
16
Hinge
Pin
Plastic Washer
REVERSING THE DOOR SWING
(continued)
RELOCATE THE PLASTIC-COVERED
SNACKS DRAWER.
(on some models)
For convenient access to the Snacks drawer
after reversing the door swing, you can move the
drawer to the other side of the cabinet.
1. Slide the drawer out and remove the shelf
to which it was attached.
2. Remove the other half-width shelf.
3. Push the drawer cover forward and up
off the shelf.
4. Put the cover on the other half-width shelf as
shown, flush to the side with the shelf-locking
lugs. Return both shelves to the refrigerator and
slide the Snacks drawer into its relocated cover.
8
EXAMINE THE DOOR GASKETS.
Check the door gaskets all around, making sure
no gaps are visible between the gaskets and the
cabinet. If a gap shows, try stretching the gasket
away from the door so the magnet in the gasket
will contact the cabinet surface, being careful not
to dislodge the gasket.
7

GE 14 Specifications

General

Brand	GE
Category	Refrigerator
Type	Top Freezer
Voltage	120 V
Color	White
Total Capacity	14 cu ft
