Installation Instructions
5.4 Transfer Freezer Door Handle
5.4.1Remove the screw holding the handle to the
top of the door and the two screws holding
the handle to the bottom of the door.
5.4.2 Remove the handle.
5.4.3 Remove the screw from the right top edge of the
door and insert it into the handle screw hole on
the left side.
5.4 Transfer Freezer Door Handle (cont.)
5.4.4Transfer the door stop as shown on the
preceding page.
5.4.5 Attach the handle to the right edge of the door
with screws at top and bottom, using bottom
holes vacated by removal of the door stop screws.
