1–112 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
44344 10F7 Binary In Point 61 Entry
Information Number
0 255 1 F1 0
44345 10F8 Binary In Point 62 Entry Function
Type
0 255 1 F1 0
44346 10F9 Binary In Point 62 Entry
Information Number
0 255 1 F1 0
44347 10FA Binary In Point 63 Entry Function
Type
0 255 1 F1 0
44348 10FB Binary In Point 63 Entry
Information Number
0 255 1 F1 0
DNP / IEC60870-5-103 BINARY OUTPUT POINTS
44349 10FC Binary Out Point 0 Entry Function
Type
0 255 1 F1 0
44350 10FD Binary Out Point 0 Entry
Information Number
0 255 1 F1 0
44351 10FE Binary Out Point 1 Entry Function
Type
0 255 1 F1 0
44352 10FF Binary Out Point 1 Entry
Information Number
0 255 1 F1 0
44353 1100 Binary Out Point 2 Entry Function
Type
0 255 1 F1 0
44354 1101 Binary Out Point 2 Entry
Information Number
0 255 1 F1 0
44355 1102 Binary Out Point 3 Entry Function
Type
0 255 1 F1 0
44356 1103 Binary Out Point 3 Entry
Information Number
0 255 1 F1 0
44357 1104 Binary Out Point 4 Entry Function
Type
0 255 1 F1 0
44358 1105 Binary Out Point 4 Entry
Information Number
0 255 1 F1 0
44359 1106 Binary Out Point 5 Entry Function
Type
0 255 1 F1 0
44360 1107 Binary Out Point 5 Entry
Information Number
0 255 1 F1 0
44361 1108 Binary Out Point 6 Entry Function
Type
0 255 1 F1 0
44362 1109 Binary Out Point 6 Entry
Information Number
0 255 1 F1 0
44363 110A Binary Out Point 7 Entry Function
Type
0 255 1 F1 0
44364 110B Binary Out Point 7 Entry
Information Number
0 255 1 F1 0
44365 110C Binary Out Point 8 Entry Function
Type
0 255 1 F1 0
44366 110D Binary Out Point 8 Entry
Information Number
0 255 1 F1 0
44367 110E Binary Out Point 9 Entry Function
Type
0 255 1 F1 0
44368 110F Binary Out Point 9 Entry
Information Number
0 255 1 F1 0
44369 1110 Binary Out Point 10 Entry
Function Type
0 255 1 F1 0
44370 1111 Binary Out Point 10 Entry
Information Number
0 255 1 F1 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
