CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–115
44429 114C 103 Second ASDU Fourth
Analogue Factor
00xFFFF1F30
44430 114D 103 Second ASDU Fourth
Analogue Offset
00xFFFF1F10
44431 114E 103 Second ASDU Fifth Analogue
Entry
0 46 1 F88A 0
44432 114F 103 Second ASDU Fifth Analogue
Factor
00xFFFF1F30
44433 1150 103 Second ASDU Fifth Analogue
Offset
00xFFFF1F10
44434 1151 103 Second ASDU Sixth Analogue
Entry
0 46 1 F88A 0
44435 1152 103 Second ASDU Sixth Analogue
Factor
00xFFFF1F30
44436 1153 103 Second ASDU Sixth Analogue
Offset
00xFFFF1F10
44437 1154 103 Second ASDU Seventh
Analogue Entry
0 46 1 F88A 0
44438 1155 103 Second ASDU Seventh
Analogue Factor
00xFFFF1F30
44439 1156 103 Second ASDU Seventh
Analogue Offset
00xFFFF1F10
44440 1157 103 Second ASDU Eigth Analogue
Entry
0 46 1 F88A 0
44441 1158 103 Second ASDU Eigth Analogue
Factor
00xFFFF1F30
44442 1159 103 Second ASDU Eigth Analogue
Offset
00xFFFF1F10
44443 115A 103 Second ASDU Ninth
Analogue Entry
0 46 1 F88A 0
44444 115B 103 Second ASDU Ninth
Analogue Factor
00xFFFF1F30
44445 115C 103 Second ASDU Ninth
Analogue Offset
00xFFFF1F10
44446 115D 103 Third ASDU Identification
Type
3 9 1 FC221 3
44447 115E 103 Third ASDU Function Type 0 255 1 F1 0
44448 115F 103 Third ASDU Information
Number
0 255 1 F1 0
44449 1160 103 Third ASDU Scan Timeout 0 1000 1 F1 0
44450 1161 103 Third ASDU First Analogue
Entry
0 46 1 F88A 0
44451 1162 103 Third ASDU First Analogue
Factor
00xFFFF1F30
44452 1163 103 Third ASDU First Analogue
Offset
00xFFFF1F10
44453 1164 103 Third ASDU Second Analogue
Entry
0 46 1 F88A 0
44454 1165 103 Third ASDU Second Analogue
Factor
00xFFFF1F30
44455 1166 103 Third ASDU Second Analogue
Offset
00xFFFF1F10
44456 1167 103 Third ASDU Third Analogue
Entry
0 46 1 F88A 0
44457 1168 103 Third ASDU Third Analogue
Factor
00xFFFF1F30
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
