CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–121
44748 128B DATASET ITEM 16 0 0xFFFF 1 FC134B 0
44749 128C ITEM 16 QUALITY 0 1 1 FC126 0
44750 128D DATASET ITEM 17 0 0xFFFF 1 FC134B 0
44751 128E ITEM 17 QUALITY 0 1 1 FC126 0
44752 128F DATASET ITEM 18 0 0xFFFF 1 FC134B 0
44753 1290 ITEM 18 QUALITY 0 1 1 FC126 0
44754 1291 DATASET ITEM 19 0 0xFFFF 1 FC134B 0
44755 1292 ITEM 19 QUALITY 0 1 1 FC126 0
44756 1293 DATASET ITEM 20 0 0xFFFF 1 FC134B 0
44757 1294 ITEM 20 QUALITY 0 1 1 FC126 0
44758 1295 DATASET ITEM 21 0 0xFFFF 1 FC134B 0
44759 1296 ITEM 21 QUALITY 0 1 1 FC126 0
44760 1297 DATASET ITEM 22 0 0xFFFF 1 FC134B 0
44761 1298 ITEM 22 QUALITY 0 1 1 FC126 0
44762 1299 DATASET ITEM 23 0 0xFFFF 1 FC134B 0
44763 129A ITEM 23 QUALITY 0 1 1 FC126 0
44764 129B DATASET ITEM 24 0 0xFFFF 1 FC134B 0
44765 129C ITEM 24 QUALITY 0 1 1 FC126 0
44766 129D DATASET ITEM 25 0 0xFFFF 1 FC134B 0
44767 129E ITEM 25 QUALITY 0 1 1 FC126 0
44768 129F DATASET ITEM 26 0 0xFFFF 1 FC134B 0
44769 12A0 ITEM 26 QUALITY 0 1 1 FC126 0
44770 12A1 DATASET ITEM 27 0 0xFFFF 1 FC134B 0
44771 12A2 ITEM 27 QUALITY 0 1 1 FC126 0
44772 12A3 DATASET ITEM 28 0 0xFFFF 1 FC134B 0
44773 12A4 ITEM 28 QUALITY 0 1 1 FC126 0
44774 12A5 DATASET ITEM 29 0 0xFFFF 1 FC134B 0
44775 12A6 ITEM 29 QUALITY 0 1 1 FC126 0
44776 12A7 DATASET ITEM 30 0 0xFFFF 1 FC134B 0
44777 12A8 ITEM 30 QUALITY 0 1 1 FC126 0
44778 12A9 DATASET ITEM 31 0 0xFFFF 1 FC134B 0
44779 12AA ITEM 31 QUALITY 0 1 1 FC126 0
44780 12AB DATASET ITEM 32 0 0xFFFF 1 FC134B 0
44781 12AC ITEM 32 QUALITY 0 1 1 FC126 0
IEC61850 GOOSE RX1 CONFIGURATION
44786 12B1 RX GOOSE1 FUNCTION 0 1 1 FC126 0
44787 12B2 RX GOOSE1 ID 0 20 1 F22 148
44807 12C6 INCOMING DS NAME 0 20 1 F22 147
44827 12DA RX1 CTRL BLCK NAME 0 20 1 F22 149
44847 12EE RX1 DS CONFIG REV 1 0xFFFF 1 F1 1
44848 12EF ETYPE APPID 0 0x3FFF 1 F1 0
IEC61850 GOOSE RX2 CONFIGURATION
44852 12F3 RX GOOSE2 FUNCTION 0 1 1 FC126 0
44853 12F4 RX GOOSE2 ID 0 20 1 F22 150
44873 1308 INCOMING DS NAME 0 20 1 F22 147
44893 131C RX2 CTRL BLCK NAME 0 20 1 F22 151
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
