1–126 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
46151 1806 RI 28 ITEM SOURCE 0 0xFFFF 1 FC217 0
46152 1807 RI 28 ITEM MASK 0 0xFFFF 1 FC218 0
46153 1808 RI 28 DFLT STATE 0 3 1 FC220 1
46155 180A RI 29 NAME 0 7 1 F22 140
46171 181A RI 29 GOOSE SOURCE 0 0x80 1 F1 0
46172 181B RI 29 ITEM SOURCE 0 0xFFFF 1 FC217 0
46173 181C RI 29 ITEM MASK 0 0xFFFF 1 FC218 0
46174 181D RI 29 DFLT STATE 0 3 1 FC220 1
46176 181F RI 30 NAME 0 7 1 F22 141
46192 182F RI 30 GOOSE SOURCE 0 0x80 1 F1 0
46193 1830 RI 30 ITEM SOURCE 0 0xFFFF 1 FC217 0
46194 1831 RI 30 ITEM MASK 0 0xFFFF 1 FC218 0
46195 1832 RI 30 DFLT STATE 0 3 1 FC220 1
46197 1834 RI 31 NAME 0 7 1 F22 142
46213 1844 RI 31 GOOSE SOURCE 0 0x80 1 F1 0
46214 1845 RI 31 ITEM SOURCE 0 0xFFFF 1 FC217 0
46215 1846 RI 31 ITEM MASK 0 0xFFFF 1 FC218 0
46216 1847 RI 31 DFLT STATE 0 3 1 FC220 1
46218 1849 RI 32 NAME 0 7 1 F22 143
46234 1859 RI 32 GOOSE SOURCE 0 0x80 1 F1 0
46235 185A RI 32 ITEM SOURCE 0 0xFFFF 1 FC217 0
46236 185B RI 32 ITEM MASK 0 0xFFFF 1 FC218 0
46237 185C RI 32 DFLT STATE 0 3 1 FC220 1
LOGIC ELEMENT NAMES
46240 185F Logic Element 1 Name 0 9 1 F22 167
46249 1868 Logic Element 2 Name 0 9 1 F22 168
46258 1871 Logic Element 3 Name 0 9 1 F22 169
46267 187A Logic Element 4 Name 0 9 1 F22 170
46276 1883 Logic Element 5 Name 0 9 1 F22 171
46285 188C Logic Element 6 Name 0 9 1 F22 172
46294 1895 Logic Element 7 Name 0 9 1 F22 173
46303 189E Logic Element 8 Name 0 9 1 F22 174
PROTECTION FUNCTION BLOCKING
46344 18C7 XFMR Block 1 0 0x1DF 1 F89 0
46345 18C8 XFMR Block 2 0 0x1DF 1 F89 0
46346 18C9 XFMR Block 3 0 0x1DF 1 F89 0
46347 18CA RGF 1 Block1 0 0x1DF 1 F89 0
46348 18CB REF 1 Block2 0 0x1DF 1 F89 0
46349 18CC RGF 1 Block3 0 0x1DF 1 F89 0
46350 18CD RGF 2 Block1 0 0x1DF 1 F89 0
46351 18CE RGF 2 Block2 0 0x1DF 1 F89 0
46352 18CF RGF 2 Block3 0 0x1DF 1 F89 0
46353 18D0 Inst Diff Block1 0 0x1DF 1 F89 0
46354 18D1 Inst Diff Block2 0 0x1DF 1 F89 0
46355 18D2 Inst Diff Block3 0 0x1DF 1 F89 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
