1–134 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
0x80 Virtual Input 1
0x81 Virtual Input 2
0x82 Virtual Input 3
0x83 Virtual Input 4
0x84 Virtual Input 5
0x85 Virtual Input 6
0x86 Virtual Input 7
0x87 Virtual Input 8
0x88 Virtual Input 9
0x89 Virtual Input 10
0x8A Virtual Input 11
0x8B Virtual Input 12
0x8C Virtual Input 13
0x8D Virtual Input 14
0x8E Virtual Input 15
0x8F Virtual Input 16
0x90 Virtual Input 17
0x91 Virtual Input 18
0x92 Virtual Input 19
0x93 Virtual Input 20
0x94 Virtual Input 21
0x95 Virtual Input 22
0x96 Virtual Input 23
0x97 Virtual Input 24
0x98 Virtual Input 25
0x99 Virtual Input 26
0x9A Virtual Input 27
0x9B Virtual Input 28
0x9C Virtual Input 29
0x9D Virtual Input 30
0x9E Virtual Input 31
0x9F Virtual Input 32
0XC0 Logic Element 1
0XC1 Logic Element 2
0XC2 Logic Element 3
0XC3 Logic Element 4
0XC4 Logic Element 5
0XC5 Logic Element 6
0XC6 Logic Element 7
0XC7 Logic Element 8
F91 signed 16 bits Edit Group
-1 Active Group
0SP Group 1 Active
1SP Group 2 Active
F95 unsigned 16 bits Transient Recorder Buffer
0 1 x 192
1 3 x 64
Code Type Definition
