GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–137
0x00D9 Virtual Output 26
0x00DA Virtual Output 27
0x00DB Virtual Output 28
0x00DC Virtual Output 29
0x00DD Virtual Output 30
0x00DE Virtual Output 31
0x00DF Virtual Output 32
0x8001 Any Trip PickUp
0x8002 Any Trip
0x8004 Any Trip DropOut
0xA001 Any Alarm PickUp
0xA002 Any Alarm
0xA004 Any Alarm DropOut
0xC002 Any Stop
0xD000 Input 1
0xD001 Input 2
0xD002 Input 3
FC134 unsigned 16 bits Cause of Event
0No Evnt/Trp ToDate
1Ctrl. Pwr Lost
2 Ctrl. Pwr Applied
3 Date or Time Set
4 Reset
6 Factory Reload
7Clock Not Set
8IRIG-B Failure
9 Reset Trip Counter
10 BKR Status Unknown
11 Clear Event Rec
12 Clear Transt Rec
13 Clear Therm Cap
14 Comm. Alert 1
15 Comm. Alert 2
16 Comm. Alert 3
17 Ethernet Link Fail
18 High ENET Traffic
19 Ambient Temp. >80C
21 BKR2 Status Unkwn
23 Trace Mem. Trigger
0x0040 Contact IN 1 On
0x0041 Contact IN 2 On
0x0042 Contact IN 3 On
0x0043 Contact IN 4 On
0x0044 Contact IN 5 On
0x0045 Contact IN 6 On
0x0046 Contact IN 7 On
0x0047 Contact IN 8 On
Code Type Definition
