CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–151
0xF7C4 Inst Diff Block DPO
0xF802 NSeq TOC1 Block
0xF804 NSeq TOC1 Block DPO
0xF842 NSeq TOC2 Block
0xF844 NSeq TOC2 Block DPO
0xF9C2 SGnd TOC2 Block
0xF9C4 SGnd TOC2 Block DPO
0xFB02 Trip BKR1 Block
0xFB04 Trip BKR1 Block DPO
0xFB42 Trip BKR2 Block
0xFB44 Trip BKR2 Block DPO
0xFB82 2nd Hmnc Diff Block
0xFB84 2nd Hmnc Diff Block DPO
0xFBC2 5th Hmnc Diff Block
0xFBC4 5th Hmnc Diff Block DPO
FC134B unsigned 16 bits DNP Binary Inputs
0Off
0x0040 Contact IN 1 On
0x0041 Contact IN 2 On
0x0042 Contact IN 3 On
0x0043 Contact IN 4 On
0x0044 Contact IN 5 On
0x0045 Contact IN 6 On
0x0046 Contact IN 7 On
0x0047 Contact IN 8 On
0x0048 Contact IN 9 On
0x0049 Contact IN 10 On
0x0060 Contact IN 1 Off
0x0061 Contact IN 2 Off
0x0062 Contact IN 3 Off
0x0063 Contact IN 4 Off
0x0064 Contact IN 5 Off
0x0065 Contact IN 6 Off
0x0066 Contact IN 7 Off
0x0067 Contact IN 8 Off
0x0068 Contact IN 9 Off
0x0069 Contact IN 10 Off
0x0080 Virtual IN 1 On
0x0081 Virtual IN 2 On
0x0082 Virtual IN 3 On
0x0083 Virtual IN 4 On
0x0084 Virtual IN 5 On
0x0085 Virtual IN 6 On
0x0086 Virtual IN 7 On
0x0087 Virtual IN 8 On
0x0088 Virtual IN 9 On
0x0089 Virtual IN 10 On
Code Type Definition
