CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–163
0x00001000 Input/Output 13
0x00002000 Input/Output 14
0x00004000 Input/Output 15
0x00008000 Input/Output 16
0x00010000 Input/Output 17
0x00020000 Input/Output 18
0x00040000 Input/Output 19
0x00080000 Input/Output 20
0x00100000 Input/Output 21
0x00200000 Input/Output 22
0x00400000 Input/Output 23
0x00800000 Input/Output 24
0x01000000 Input/Output 25
0x02000000 Input/Output 26
0x04000000 Input/Output 27
0x08000000 Input/Output 28
0x10000000 Input/Output 29
0x20000000 Input/Output 30
0x40000000 Input/Output 31
0x80000000 Input/Output 32
FC169 unsigned 16 bits Month
0 Not Set
1 January
2February
3March
4April
5May
6 June
7July
8 August
9September
10 October
11 November
12 December
FC170 unsigned 16 bits Count of Week
0 NotSet
11st
22nd
33rd
44th
5Last
FC171 unsigned 16 bits Weekdays
0 Not Set
1SUN
2MON
3TUE
4WED
Code Type Definition
