GE 345

CHAPTER 1: COMMUNICATIONS GUIDE MODBUS MEMORY MAP
345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE 1–165
FC183 unsigned 32 bits Trip Status 1
0x00000001 Any Trip
0x00000002 Therm O/L Trip
0x00080000 LE 1 Trip
0x00100000 LE 2 Trip
0x00200000 LE 3 Trip
0x00400000 LE 4 Trip
0x00800000 LE 5 Trip
0x01000000 LE 6 Trip
0x02000000 LE 7 Trip
0x04000000 LE 8 Trip
FC185 unsigned 32 bits Trip Status 3
0x00000001 Phase IOC 1 Trip
0x00000002 Neutral IOC1 Trip
0x00000004 Ground IOC 1 Trip
0x00000008 Phase TOC Trip
0x00000010 Neutral TOC Trip
0x00000020 Ground TOC Trip
0x00000040 Phase IOC 2 Trip
0x00000080 Neutral IOC2 Trip
0x00000100 Ground IOC 2 Trip
0x00001000 SGnd TOC Trip
0x02000000 SGnd IOC 1 Trip
0x04000000 SGnd IOC 2 Trip
0x10000000 Diff 87P Trip
0x20000000 Diff 87REF 1 Trip
0x40000000 Diff 87REF 2 Trip
0x80000000 Inst 50/87P Trip
FC186 unsigned 32 bits Trip Status 3
0x00000001 NSeq TOC1 Trip
0x00000002 NSeq TOC2 Trip
0x00000080 SGnd TOC2 Trip
FC187 unsigned 32 bits Message Status 1
0x00000000 No Messages
0x00000001 Any Messages
0x00000040 Clock Not Set
0x00000100 BKR Status Unknown
0x00000200 Relay Not Ready
0x00000400 IRIG-B Failure
0x00000800 Comm. Alert 1
0x00001000 Comm. Alert 2
0x00002000 Comm. Alert 3
0x00004000 Ethernet Link Fail
0x00008000 High ENET Traffic
0x00010000 Ambient Temp. >80C
FC188 unsigned 32 bits Message Status 2
0x00000001 Order Code Error
Code Type Definition
