A value of FF 00 hex requests the coil to be ON. A value of 00 00 requests it to be OFF. All
other values are illegal and will not affect the coil.
Force Virtual Inputs:
Commands:
Description Coil Address (HEX) Description Coil Address (HEX)
Virtual Input 1 0x1000 Virtual Input 17 0x1010
Virtual Input 2 0x1001 Virtual Input 18 0x1011
Virtual Input 3 0x1002 Virtual Input 19 0x1012
Virtual Input 4 0x1003 Virtual Input 20 0x1013
Virtual Input 5 0x1004 Virtual Input 21 0x1014
Virtual Input 6 0x1005 Virtual Input 22 0x1015
Virtual Input 7 0x1006 Virtual Input 23 0x1016
Virtual Input 8 0x1007 Virtual Input 24 0x1017
Virtual Input 9 0x1008 Virtual Input 25 0x1018
Virtual Input 10 0x1009 Virtual Input 26 0x1019
Virtual Input 11 0x100A Virtual Input 27 0x101A
Virtual Input 12 0x100B Virtual Input 28 0x101B
Virtual Input 13 0x100C Virtual Input 29 0x101C
Virtual Input 14 0x100D Virtual Input 30 0x101D
Virtual Input 15 0x100E Virtual Input 31 0x101E
Virtual Input 16 0x100F Virtual Input 32 0x101F
Description Coil Address (DEC)
eCmdNone 0
eCmdReset 1
eCmdLockoutReset 2
eCmdStop 3
eCmdOpen 4
eCmdClose 5
eCmdDisplayMessage 6
eCmdChangeToSetpointGroup1 7
eCmdChangeToSetpointGroup2 8
eCmdChangeToSetpointGroup3 9
eCmdChangeToSetpointGroup4 10
eCmdCO1_ON 32
eCmdCO1_ON 32
eCmdCO1_Off 33
eCmdCO2_On 34
eCmdCO2_Off 35
eCmdCO3_On 36
eCmdCO3_Off 37
eCmdCO4_On 38
eCmdCO4_Off 39
eCmdCO5_On 40
eCmdCO5_Off 41
