32 0 Analog Change Event
(Variation 0 is used to
request default
variation)
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
--- ---
1 32-Bit Analog Change
Event without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129
(response)
130 (unsol.
resp.)
17, 28
(index)
2 16-Bit Analog Change
Event without Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129
(response)
130 (unsol.
resp.)
17, 28
(index)
3 32-Bit Analog Change
Event with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129
(response)
130 (unsol.
resp.)
17, 28
(index)
4 16-Bit Analog Change
Event with Time
1 (read) 06 (no range, or all)
07, 08 (limited
quantity)
129
(response)
130 (unsol.
resp.)
17, 28
(index)
34 0 Analog Input Reporting
Deadband (Variation 0 is
used to request
defaultvariation)
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity) 17, 28
(index)
--- ---
1 16-bit Analog Input
Reporting Deadband
(default - see Note 1)
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity) 17, 28
(index)
129
(response)
00, 01
(start-stop)
17, 28
(index) (see
Note 2)
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity) 17, 28
(index)
--- ---
2 32-bit Analog Input
Reporting Deadband
1 (read) 00, 01 (start-stop)
06 (no range, or all)
07, 08 (limited
quantity) 17, 28
(index)
129
(response)
00, 01
(start-stop)
17, 28
(index) (see
Note 2)
2 (write) 00, 01 (start-stop)
07, 08 (limited
quantity) 17, 28
(index)
--- ---
50 1 Time and Date (default -
see Note 1)
1 (read)2
(write)
00, 01 (start-stop)
06 (no range, or all)
07 (limited qty=1) 08
(limited quantity)
17, 28 (index)
129
(response)
00, 01
(start-stop)
17, 28
(index) (see
Note 2)
52 2 Time Delay Fine
(quantity = 1)
129
(response)
07 (limited quantity) --- ---
60 0 Class 0, 1, 2, and 3 Data 1 (read) 20
(enable
unsol) 21
(disable
unsol) 22
(assign
class)
06 (no range, or all) --- ---
1 Class 0 Data 1 (read) 22
(assign
class)
06 (no range, or all) --- ---
OBJECT REQUEST RESPONSE
OBJECT
NO.
VARIATION
NO.
DESCRIPTION FUNCTION
CODES
(DEC)
QUALIFIER CODES
(HEX)
FUNCTION
CODES
(DEC)
QUALIFIER
CODES
(HEX)
