1–80 345 TRANSFORMER PROTECTION SYSTEM – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP CHAPTER 1: COMMUNICATIONS GUIDE
30695 2B6 Ph C Diff. 0 65535 1 F3 0
30696 2B7 Ph A Restr. 0 65535 1 F3 0
30697 2B8 PH A THERMAL CAP 0 1500 1 F2 0
30697 2B8 Ph B Restr. 0 65535 1 F3 0
30698 2B9 PH B THERMAL CAP 0 1500 1 F2 0
30698 2B9 Ph C Restr. 0 65535 1 F3 0
30699 2BA PH C THERMAL CAP 0 1500 1 F2 0
30699 2BA 2nd Harm Ph A diff 0 65535 1 F2 0
30700 2BB 2nd Harm Ph B diff 0 65535 1 F2 0
30701 2BC 2nd Harm Ph C diff 0 65535 1 F2 0
30702 2BD Thermal Capacity A 0 1500 1 F2 0
30703 2BE Thermal Capacity B 0 1500 1 F2 0
30704 2BF Thermal Capacity C 0 1500 1 F2 0
30705 2C0 Self-Test Event 0 0xFFFFFFFF 2 FC188 0
TRANSIENT RECORDER
30707 2C2 Transient Recorder Last Cleared 0x010107D8 0X0C1F082E 0 F18 0x010107D8
30709 2C4 Transient Recorder Available
Records
0 65535 1 F1 0
30710 2C5 Trigger Date 0x010107D8 0X0C1F082E 0 F18 0x010107D8
30712 2C7 Trigger Time 0 0X173B3B63 0 F19 0
30714 2C9 Trigger Cause 0 0xD002 0 FC133 0
30715 2CA Trigger Frequency 20 120 1 F3 60
30716 2CB Total Triggers 0 0xFFFF 1 F1 0
30718 2CD Trigger Position 0 100 1 F1 25
30719 2CE Trace Memory Start Index 0 6143 1 F1 0
30720 2CF Sample Index + Trace Memory
Sample 1
-32767 32767 1 F4 0
30721 2D0 Sample Index + Trace Memory
Sample 2
-32767 32767 1 F4 0
30722 2D1 Sample Index + Trace Memory
Sample 3
-32767 32767 1 F4 0
30723 2D2 Sample Index + Trace Memory
Sample 4
-32767 32767 1 F4 0
30724 2D3 Sample Index + Trace Memory
Sample 5
-32767 32767 1 F4 0
30725 2D4 Sample Index + Trace Memory
Sample 6
-32767 32767 1 F4 0
30726 2D5 Sample Index + Trace Memory
Sample 7
-32767 32767 1 F4 0
30727 2D6 Sample Index + Trace Memory
Sample 8
-32767 32767 1 F4 0
30728 2D7 Sample Index + Trace Memory
Sample 9
-32767 32767 1 F4 0
30729 2D8 Sample Index + Trace Memory
Sample 10
-32767 32767 1 F4 0
30730 2D9 Sample Index + Trace Memory
Sample 11
-32767 32767 1 F4 0
30731 2DA Sample Index + Trace Memory
Sample 12
-32767 32767 1 F4 0
30732 2DB Sample Index + Trace Memory
Sample 13
-32767 32767 1 F4 0
Modbus
Address
Hex
Address
Description Min Max Step Format
Code
Factory
Default
