PARTS
13
s
e
l
f
c
l
e
a
n
max
auto
shutoff
1
6
11
2
3
5
4
7 8
14
9
10
12
1516
1. Spray nozzle
2. Fill inlet cover
3. Fill inlet
4. Function control
: steam ironing
: steam output
: dry ironing
5. Spray button
6. Steam burst button
7. Handle
8. Retractable power cord with plug
9. Cord storage
10. Cord retraction button
11. Heel
12. Operation indicator
13. Temperature control
cotton-linen
: highest temp.
silk-wool : medium temp.
synthetics : low temp.
o:  applianceo
14. self clean button
15. Water tank
16. Soleplate with steam nozzles
