44
Service Manual
Installation and Maintenance
NO.
Description
Part Code
QtyAEE18KP
Product Code CC052006100_K93320
1 Cabinet Assy 014316181 1
2 Condenser Assy 01101704 1
3 Axial Flow Fan 10331163 1
4 Rear Clapboard 01231701 1
5 Motor Support 1 01701605 1
6 Fan Motor 1501105804 1
7 Motor Support 2 01701604 1
8 Top Cover Board Sub-assy 01251611 1
9 Front Clapboard Sub-Assy 01231607 1
10 Base Plate Of Air Flue 01221602 1
11 Propeller Housing 12101602 1
12 Air Outlet Sub-Assy 2000103601 1
13 Air Door Lever 10581601 1
14 Swing Lever 10581602 1
15 Swing Lever2 10581021 1
16 Step Motor 1521211601 1
17 Swing Blade Support 10581603 1
18 Crank 73011001 1
19 Air Louver 10511601 2
20 Centrifugal Fan 10311602 1
21 Front Clapboard of Propeller Housing 01231604 1
22 Evaporator Assy 01001703 1
23 Compressor and Fittings 00101155 1
24 Compressor Overload Protector(External) 00181019/00181021 1
25 Compressor Gasket 76711005 3
26 Capillary Sub-assy 03001261 1
27 Inhalation Tube Sub-assy 03631866 1
28 Discharge Tube 03611657 1
29 Water Tray 12411007 1
30 Chassis Sub-assy 01201104P 1
31 Drainage hole Cap 76711012 1
32 Cabinet Fastener 26251601 1
33 Chassis Clamp 01211601 1
34 Power Cord 4002048915 1
35 Electric Box Assy 20101447 1
36 Capacitor CBB61 33010009 1
37 Capacitor CBB65 33010743 1
38 Electric Box 20111018 1
39 Transformer 43110236 1
40 Main Board 30132096 1
41 Temperature Sensor 390000596 1
42 Ambient Temperature Sensor 390000451 1
