49-7788 13
Installation Instructions
INSTALLATION INSTRUCTIONS
INSTALL FOAM INSULATION
Additional insulation is provided with your
window air conditioner to reduce heat
leakage into the home, reducing overall
energy usage.
A. After the air conditioner is installed in the
window measure the length of the accordion
for both sides.
B. Cut the foam insulation to the measured
length of the left and right side accordion.
NOTE: Be sure to measure each accordion
because the length could be different on
each side.
C. Remove adhesive from back of foam
insulation. Stick the foam insulation onto
the left and right accordion, and inside of the
frames.
NOTE: be careful to cover the entire
accordion.
/
+
/
+
