31-5000560 Rev. 5 7
COMPATIBILITY MATRIX FOR MULTI ZONE DUCTLESS SYSYTEM
Installation Instructions
ASH218JCDDA / ASH220NCDDA COMBINATIONS
PORT A PORT B
Port Size 1/4" X 3/8" 1/4" X 3/8"
Adapter No adapter required No adapter required
TWO ZONE
7k 7k
7k 9k
9k 9k
7k 12k
9k 12k
12k 12k
ASH324JCDDA / ASH324NCDDA COMBINATIONS
PORT A PORT B PORT C
Port Size 1/4" X 3/8" 1/4" X 3/8"
JC: 1/4" X 3/8"
NC: 1/4" X 1/2"
Adapter No adapter required
No adapter re-
quired
Port C Required Adapter
JC NC
TWO ZONE
-7k7k-E
-7k9k-E
-9k9k-E
- 7k 12k - E
- 9k 12k - E
- 12k 12k - E
- 7k 18k D -
- 9k 18k D -
- 12k 18k D -
THREE ZONE
7k 7k 7k - E
7k 7k 9k - E
7k 9k 9k - E
7k 7k 12k - E
9k 9k 9k - E
7k 9k 12k - E
9k 9k 12k - E
7k 12k 12k - E
7k 7k 18k D -
9k 12k 12k - E
Models that may require adapters
*1 - These 24K models require 3/8" liquid and 5/8" vapor linesets
USYM24UCDDA USYM24UCDSA USYL24UCDSA AL24LP2VHA
*2 - These 24K models require 1/4" liquid and 1/2" vapor linesets
ASYW24CRDDA
All 18K models require 1/4" liquid and 1/2" vapor linesets
All 7K, 9K, and 12K models require 1/4" liquid and 3/8" vapor linesets
ADAPTERS GEA PART#
A
1/4" to 3/8"
flare Adapter
WJ01X23925
B
3/8" to 5/8"
flare Adapter
WJ01X23924
C
1/2" to 5/8"
flare Adapter
WJ01X23932
D
3/8" to 1/2"
flare Adapter
WJ01X26853
E
1/2" to 3/8"
flare Adapter
WJ01X26854
