GE Cafe CWE23SSHDSS User Manual

DIMENSIONS
22
Installation Instructions
Case Depth w/o
Doors 29
3
ø8
”
CFE
24
3
ø8
”
CYE
Height from
floor to hinge
cover top 69
7
ø8”
Additional Dimensions
23
1
ø4” CFE
18
1
ø4” CYE
All measurements are given with leveling leg fully retracted.
CFE CYE
Overall Height to Top of
Hinge Cover
69
7
ø8
”69
7
ø8
”
Height to Top of Cabinet
69” 69”
Case Depth without Doors
29
3
ø8
”24
3
ø8
Overall Exterior Case Width
35
3
ø4”35
3
ø4”
Overall Exterior Depth
Doors/Drawers with Handles
36¼” 31¼”
• Using the chart below determine if the width of your passageway can accommodate the depth of the refrigerator.
Ensure you have clearance to prevent damage to the refrigerator before safely moving it to the final location.
• If passageways are large enough to accommodate the refrigerator without removing the handles skip to Step 6. Leave
tape, film and all packaging on doors until the refrigerator is in the final location.
• NOTE: Use a padded hand truck or moving straps to move this refrigerator. Place the refrigerator on the hand truck
with a side against the truck. We strongly recommend that two people move and complete this installation.
If your model number starts with CFE
If your model number starts with CYE
MOVING THE REFRIGERATOR
CFE OnlyCYE Only
35
3
ø4”35
3
ø4”
69”69”
36
1
ø4”31
1
ø4”
69
7
ø8
”69
7
ø8
”
36.25” 35.25” 29.375”
33.75” 30.25”
31.25”
30.25”
28.75”
24.375”
25.25”
