rools
Needed
Standard #2 Phillips screwdriver
Tape-tipped putty
hife
Needle-nosed pliers
Dryer Door
1.
Open the door and
remove the filler plugs
opposite the hinges.
2. With the door completely
open, remove the bottom
screw from each hinge
on the dryer face.
f
9
3. Insert these screws
*
about
hdf
way into
k
the
BO~OM
holes,
for each hinge, on the
.-
opposite side.
mere
you removed the filler plugs.)
4.
Loosen the top screw from each hinge on the dryer
face
hdf
way.
5. With one hand holding
the top of the door and
the other hand holding
the bottom, remove the
door from the dryer by
lifting it UP and OUT.
the two screws.
Attention: The door must be held firmly in place
until the two screws are tightened.
7.
With the other screws,
secure each hinge at
the top.
‘
@
,
8
-%
00
II
8.
Tighten the two top
screws of each hinge.
9.
Reinsert the plastic plugs on the side from which
the door was removed.
13
