22 49-60792-2
Freezer Basket and Drawer
Basket.
'UDZHU
,FH%XFNHW$YDLODEOHRQ1RQ'LVSHQVHPRGHOV
RQO\$YDLODEOHDVD,0.LWRQVRPHPRGHOV
Non-Adjustable Bin in the Freezer*
To remove:
Push in plastic tab on either left or right side
To replace:
Slide bin into location until it locks into place.
Basket Removal
To remove, standard depth models only:
2SHQIUHH]HUGRRUWRWKHVWRSSRVLWLRQ
5HPRYHIUHH]HUGRRUELQE\SXVKLQJSODVWLFWDERQ
either left or right side to release bin hinge pin.
5HPRYHIUHH]HUEDVNHWE\OLIWLQJXSWKHUHDURIWKH
basket and moving basket rearward until the front of
the basket can be rotated upward and out.
4. Lift it out to remove.
To remove, counter depth models only:
1. Open fresh food doors.
2SHQIUHH]HUGRRUWRWKHVWRSSRVLWLRQ
5HPRYHIUHH]HUEDVNHWE\OLIWLQJXSWKHUHDURIWKH
basket and rotate it upward.
4. Lift it out to remove.
To replace:
Reverse step 1 through 4 to replace.
*Select Models Only
Baskets, Drawers, and Bins
Plastic Tabs
USING THE FREEZER:%DVNHWV'UDZHUVDQG%LQV
