40 49-60792-2
To place rotating bin into door:
1. Slide bin base assembly onto the bracket on
the door.
2. Slide the bin onto the bin base
To place adjustable bins into door:
Position the bins over the bin locators and
push down until locked in position.
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
Bin
Bin
base
,QVWDOO
metal
base
Bin
Bin locators
Adjustable
bins
Rotating
bin
INSTALLATION INSTRUCTIONS
Models PFD, PYD, GFD
