GE EP-5261 - Parameter Configuration; Overview of Editable Parameters

4 RSTi-EP Slice I/O Serial Communication Module
GFK-2992B
Overview of Editable Parameters
Description
Options
1
Default
Operating mode
Disabled (0) / RS232 (1) / RS485 (2) / RS422 (3)
Disabled
Data bits
2
7 Bit (0) / 8 Bit (1)
8 Bit
Baud rate
300 (0) / 600 (1) / 1200 (2) / 2400 (3) / 4800 (4) / 9600 (5) / 14400 (6) /
19200 (7) / 28800 (8) / 38400 (9) / 57600 (10) / 115200 (11)
9600
Stop bit
1 Bit (0) / 2 Bit (1)
1 Bit
Parity
None (0) / Even (1) / Odd (2)
None
Flow control
None (0) / CTS/RTS (1) / XON/XOFF (2)
None
XON character
0 ... 255
17
XOFF character
0 ... 255
19
Terminating resistor
RS-485/422
Off (0) / On (1) Off
Process data length
16 Byte (1)
16 Byte
1) Values in brackets for EtherCAT and Modbus-TCP
2) Option 7 Bit works only in combination with a parity (even or odd)
For public disclosure
