49-60805-1 23
INSTRUCCIONES DE INSTALACIÓN
3
RETIRO DE LAS BISAGRAS CENTRALES
Y DE LOS SOPORTES
A. 8VDQGRXQDOODYH$OOHQGH´UHWLUHORVSHUQRV
de la bisagra desde los soportes de la bisagra
B.8VDQGRXQDOODYHGHWXERGHVWRUQLOODGRUGH´
retire los tornillos que aseguran los soportes de la
bisagra central al gabinete.
2
RETIRO DE LA PUERTA IZQUIERDA (cont.)
B. Retire la tapa de la bisagra en la parte superior
de la puerta de refrigerador izquierda, retirando el
tornillo con un destornillador Phillips.
C. 'HVHQFKXIHORVFRQHFWRUHVGHFDEOHV\PXHYD
estos últimos, hasta que pueda ver los tornillos
TXHVRVWLHQHQODELVDJUD3DUD0RGHORVFRQ+LHOR
y Agua Únicamente: empuje la tubería de agua
con mucho cuidado
D.8VDQGRXQDOODYHGHWXERGHVWRUQLOODGRUGH´
retire los tornillos que aseguran
Conectores
de los
Cables
Tubería de Agua
0RGHORVFRQ
+LHOR\$JXD
Únicamente)
Wire Connectors
%ROWV
Water Line
,FHDQG
Water
Models
2QO\
Para Modelos que NO son con Hielo y Agua
Únicamente: levante la bisagra de forma recta hacia
arriba para liberar el perno de la bisagra desde el
anclaje en la parte superior de la puerta, y pase
el cable a través de la ranura de la bisagra.. Para
Modelos con Hielo y Agua Únicamente: no retire
la bisagra de la puerta.
E. Retire la cinta de la puerta, abra la puerta a 90
grados e incline la puerta lejos del gabinete.
Levante la puerta y retire la misma del perno de la
bisagra central.
F. Ajuste la puerta en una superficie antirayaduras con
la parte interna hacia arriba.
INSTALACIÓN DEL REFRIGERADOR &RQW
