Page #1 background image

Loading...

Page #1 background image

Write the model and serial

numbers here:

Model # _________________

Serial # _________________

You can find them on a label on

the tub wall just inside the door.

GE is a trademark of the General Electric Company. Manufactured under trademark license.

OWNER’S MANUAL

DISHWASHERS

49-55114 05-17 GEA

ENGLISH/FRANÇAIS

Standard Tub Dishwashers

SAFETY INFORMATION .........4

USING THE DISHWASHER

Getting Started ........................8

Dispensers ...........................13

Loading .............................15

CARE AND CLEANING ............17

TROUBLESHOOTING TIPS ......18

WARRANTY ......................22

ACCESSORIES ...................23

CONSUMER SUPPORT ......... 24

Questions and Answers:

J
jennifer26Aug 21, 2025
Why are my dishes and flatware not clean in my GE Dishwasher?
- J
  Jaime BellAug 21, 2025
  Several factors can cause this. The inlet water temperature might be too low; raise your water heater to 120°F and use HOT START, POTS & PANS, or HEAVY WASH and HI TEMP WASH. The detergent could be low performing, old, or damp; try using a highly rated detergent like Finish® Quantum® Automatic Dishwashing Detergent. Also, low water pressure, a clogged air gap or disposer, or improper rack loading can be culprits. Normal water pressure to the dishwasher should be 20-120 psi. Make sure large dishware does not block the detergent dispenser or the wash arm.
S
Samantha MendezAug 22, 2025
What to do if my GE GSD3300KWW won’t run?
- C
  Chelsea McintyreAug 22, 2025
  Check if a fuse is blown or a circuit breaker is tripped; replace the fuse or reset the breaker, and remove other appliances from the circuit. Also, ensure the power to the dishwasher is turned on, especially if it's controlled by a wall switch.
K
Kelsey BlairAug 25, 2025
Why is there water standing in the bottom of my GE GSD3300KWW tub?
- J
  Jessica MitchellAug 25, 2025
  A small amount of clean water around the outlet on the tub bottom at the back of the tub is normal. It keeps the water seal lubricated.
M
marydavenportAug 26, 2025
How to get my GE GSD3300KWW dishes to dry?
- J
  Julie HaysAug 26, 2025
  Ensure the inlet water temperature is at least 120°F. Select HEATED DRY. Use HOT START and ADDED HEAT options. Select a higher cycle, such as POTS & PANS or HEAVY WASH. Also, check the rinse agent dispenser and fill as required.
J
Juan RochaAug 27, 2025
Why won’t water pump out of my GE GSD3300KWW tub?
- M
  melissa56Aug 28, 2025
  If you have an air gap, clean it. If the dishwasher drains into a disposer, run disposer clear. Check to see if your kitchen sink is draining well. If not, you may need a plumber.
C
Christina MckayAug 29, 2025
Why did my GE GSD3300KWW control panel responded to inputs but dishwasher never filled with water?
- R
  Rebecca GrahamAug 29, 2025
  Make sure the water valve (usually located under the sink) is turned on.
B
Bethany MooneyAug 31, 2025
How to remove white film from glassware, dishware and the interior of my GE GSD3300KWW Dishwasher?
- A
  amber27Aug 31, 2025
  The white film is likely caused by a low-quality phosphate-free dishwasher detergent. To remove it, run your dishes through a dishwasher cycle with citric acid, which can be found in a WD35X151 kit online, or use Finish® Dishwasher Cleaner. Pour the citric acid into the detergent cup, place the filmed items in the dishwasher (without silverware or metal), and run a complete cycle without detergent. A vinegar rinse may also be used. Pour 1 cup of vinegar into the dishwasher just after the detergent cup opens and let the dishwasher complete its cycle. The use of a rinse agent such as Finish® Jet-Dry® Rinse Aid may help minimize a repeat build up of film. Also, the use of a highly rated detergent such as Finish® Quantum® Automatic Dishwashing Detergent will help prevent film build-up.
R
Roger HarrisSep 1, 2025
How to prevent spots and filming on glasses and flatware in my GE Dishwasher?
- J
  John NelsonSep 1, 2025
  Several factors contribute to spots and filming. Extremely hard water is a common cause; use rinse agents like Finish® Jet-Dry® Rinse Aid, and consider a water softener if the water is extremely hard. Low inlet water temperature can also be a factor; ensure it's at least 120°F (49°C). Overloading, improper loading, old or damp detergent, an empty rinse agent dispenser, or using too little or a low performing detergent can also cause these issues. Make sure detergent is fresh. Use a highly rated detergent such as Finish® Quantum® Automatic Dishwashing Detergent. Refill rinse agent dispenser with rinse agent such as Finish® Jet-Dry® Rinse Aid. Load dishwasher as shown in the Loading section.
M
Monica SummersSep 3, 2025
How to fix cloudiness on glassware in my GE Dishwasher?
- D
  David MillerSep 3, 2025
  Cloudiness, or etching, can be caused by a combination of soft water and too much detergent, which is permanent. To prevent it, use less detergent if you have soft water and wash glassware in the shortest cycle that will get it clean. Also, water temperature entering dishwasher exceeding 150°F can be the reason. Lower the water heater temperature.
J
Jillian DuncanSep 5, 2025
How to fix black or gray marks on dishes from my GE GSD3300KWW Dishwasher?
- R
  Rachel EdwardsSep 5, 2025
  These marks occur when aluminum utensils rub against dishes. Remove them with a mild, abrasive cleaner.

GE GSD3300KWW Specifications

General

Style	built-in dishwashers
Color	white
Load Capacity	12
Number of Cycles	5
Cycle Selections	heavy wash, normal wash, plate warmer, pots & pans, rinse only
Options/Settings	heated dry on/off, hi-temp wash, hot start
Noise level	62 decibels adjusted
Number of Racks	2
Sanitize Settings	no
Smart Home	no
Annual Energy Consumption	270 kilowatt hours
Voltage	120 volts
Current	6.2 amperes

Weight and Dimensions

Depth	25 3/4 inches
Height	34 inches
Width	24 inches
Net Weight	90 pounds

Summary

Safety Information

Proper Installation and Maintenance

Safety advice for appliance installation and maintenance procedures.

General Usage Precautions

Essential safety precautions to follow during dishwasher operation and loading.

Water Heater and Child Safety

Electrical Requirements and Injury Prevention

Getting Started with Your Dishwasher

Dishwasher Options

Selecting and Understanding Options

Explanation of various operational options available for the dishwasher.

Starting Dishwasher Cycles

Using Cycle Dials

Instructions for starting the dishwasher using a cycle dial control.

Dishwasher Control Panel and Indicators

Starting Model GSD4000

Specific instructions for starting the GSD4000 model dishwasher.

Dishwasher Dispensers

Rinse Agent Dispenser

Information on checking water temperature and using the rinse agent dispenser.

Detergent Dispenser Usage

Using the Detergent Dispenser

Detailed guide on how to use the detergent dispenser correctly based on water hardness.

Dishwasher Loading Guidelines

Rack and Basket Loading

Guidelines for properly loading dishes in upper, lower racks, and silverware basket.

Troubleshooting: Cleaning and Appearance Issues

Unclean Dishes and Film

Troubleshooting: Operational and Drainage Problems

Suds, Latch, and Drying Issues

Solutions for suds, latch issues, detergent dispensing, and dishes not drying.

Water Filling and Panel Errors

Troubleshooting: Unit Not Running or Draining

Dishwasher Won't Start or Drain
