4
How to install features. (Not all features are on all models.)
Top Freezer Shelf
TOP FREEZER SHELF
Make sure the shelf front locks into
position.
Lower Door Bin
LOWER FIXED DOOR BINS
Make sure the bin fronts lock into position.
ADJUSTABLE
DOOR BINS
DOOR BIN SNUGGERS
DAIRY COVER
BOTTLE RETAINER
Door
Shelf Front
Door
Shelf
FILTER CARTRIDGE
FREEZER DOOR SHELF FRONTS
Make sure that the shelf front locks
into position.
NOTE: On dispenser models, the
longer shelf fronts go in the top
two positions.
Remove Bypass Plug Install Filter Cartridge
To remove: Lift the front
of the bin up, then pull
out.
To replace or relocate:
Engage the bin in the
molded supports of the
door, and push in. Bin
will lock in place.
To remove: Lift the shelf extender
straight up, then pull out.
To replace: Engage the shelf extender
in the molded supports of the door
and push in. It will lock in place.
About the shelves and bins. (Not all features are on all models.)
Rearranging the Shelves
To Remove
To Replace
Refrigerator Shelves:
Lift up and out
Tilt up
Insert
top hook
Lower to
lock in
place
To Remove
Freezer Shelves:
To Remove
Freezer Pan:
Remove the pan by pulling it
forward, lifting up the front and
sliding it past the stop location.
