49-1000471 Rev. 1 13
USING THE REFRIGERATOR: 5HIULJHUDWRU'RRUV
Door Alignment
,IGRRUVDUHXQHYHQDGMXVWWKHUHIULJHUDWRUGRRU
To remove the base grille, open the doors, remove the
screw at each end of the base grille and then pull the
grille straight out.
8VLQJD´VRFNHWZUHQFKWXUQWKHGRRUDGMXVWLQJ
VFUHZWRWKHULJKWWRUDLVHWKHGRRUWRWKHOHIWWR
lower it. (A nylon plug, imbedded in the threads of the
pin, prevents the pin from turning unless a wrench is
used.)
2. After one or two turns of the wrench, open and close
the refrigerator door and check the alignment at the
top of the doors.
Refrigerator Doors (on some models)
The refrigerator doors may feel different than the ones
\RXDUHXVHGWR7KHVSHFLDOGRRURSHQLQJFORVLQJ
feature makes sure the doors close all the way and are
securely sealed.
When opening and closing the door you will notice a stop
SRVLWLRQ,IWKHGRRULVRSHQHGSDVWWKLVVWRSSRLQWWKH
door will remain open to allow you to load and unload
food more easily. When the door is only partially open, it
will automatically close.
The resistance you feel at the stop position will be
reduced as the door is loaded with food.
When the door is only partially open,
it will automatically close.
Beyond this stop the door will stay open.
´6RFNHW:UHQFK
Raise
Refrigerator Doors
