GE JGBP89 - Dimensions and Clearances

29
3
/4”
Depth with door closed (includes door handle)
Depth varies depending on model.
See specifications sheet for your model.
30”
36
1
/4” ± 1/4”
To cabinets below
cooktop and at
the range back
30”
30”
6”
Minimum
13”
Minimum
clearance to
right wall
Maximum depth
for cabinets
above
countertops
Front edge of
the range side
panel forward
from cabinet
18”
0”
1/4”
Minimum to
cabinets on
either side
of the range
36”
47
3
/4”
Depth with door open:
46
3
/4”
Height
Installation Instructions
Provide adequate clearances between the range and adjacent combustible surfaces. These dimensions must be
met for safe use of your range. The location of the electrical outlet and pipe opening (see Gas Pipe and Electric
Outlet Locations) may be adjusted to meet specific requirements.
The range may be placed with 0″ clearance (flush) at the back wall.
DIMENSIONS AND CLEARANCES
44
3”
Minimum
clearance
to left wall
