LEVEL THE FREEZER DOOR
Locate the height adjuster cam in the
IUHH]HUGRRU6OLJKWO\ORRVHQWKHWKUHHGRRU
attachment screws on both sides using a
´KH[VRFNHWGULYHU
Locate and loosen the cam screw using the
T-27 screw driver.
10
A
B
REMOVE PACKAGING
Remove all tape, foam and protective
packing from shelves and drawers.
11
LEVEL THE FREEZER DOOR
(cont.)
Lift the door on the side requiring
adjustment, rotate the cam to required
position.
After adjustment tighten the 3 attachment
VFUHZVXVLQJWRLQOE1P
10
,QLWLDOSRVLWLRQ
/LIWE\´FP
/RZHUE\´FP
/RZHUE\´FP
/RZHUE\´FP
A
B
Installation Instructions
INSTALLING THE REFRIGERATOR (Cont.)
INSTALLATION INSTRUCTIONS
