Service Diagnostic Table
FZ
Display
FF
Display
Mode Comments
00 47 FF Fan Test
Turns the Fan on 75% Duty Cycle and Returns the RPM
00 48 FZ Fan Test
00 49 Condenser Fan Test
00 50 Ice Box Fan Test
00 51 Deli/QC Fan Test
00 52 Convertible Drawer Fan Test
00 53 FF Defrost Heater Test
Turns on the Load
00 54 Deli Pan/QC Heater Test
(30 sec max)
00 55 Isolation Valve Test
00 56 Ice Port Heater Test
00 57 Ice Duct Liner Htr/SxS Water
Valve Test
00 58 FZ Icemaker Water Valve Test
00 59 FZ Icemaker Rake Motor Test
00 60 FZ Defrost Heater Test
00 61 Compressor Relay Test
00 63 IMX Power Relay Test
(Normally Closed Relay)
00 64 FZ Icemaker Fill Tube Heater
Test
00 65 FF Door Icemaker Water Valve
Test
00 66 FF Door Icemaker Rake Motor
Test
00 67 FF Door Hot Water Valve Test
00 68 FF Door Water Valve Test
00 69 Hot Water Heater Test
(5 sec max)
00 70 Read Left FF Door Status
Returns the Input Status (0 = Closed, 1 = Open)
00 71 Read Right FF Door Status
00 72 Read FZ Door Status
00 73 Read Conv Drawer/IM Input
Status
00 74 Read FZ Icemaker Rake Status Returns the Input Status (0 = Not Home, 1 = Home)
00 75 Read FZ Icemaker Arm Status Returns the Input Status (0 = Not Full, 1 = Full)
00 76 Read FF Door Icemaker Rake
Status
Returns the Input Status (0 = Not Home, 1 = Home)
00 77 Read FF Door Icemaker Arm
Status
Returns the Input Status (0 = Not Full, 1 = Full)
00 78 Read FF Door Cold Water Cup
Switch
Returns the Input Status (0 = Not Pressed)
00 79 Read FF Door Hot Water Cup
Switch
(Continued next page)
