SPECIFICATION GUIDELINES.
6
Rated capacity
See rating label located on the softener.
Amount of high capacity resin (lbs/cu. ft)
52/1
Resin tank nominal size (in., dia. x height)
10 x 35
Service flow rate (gpm)
See rating label located on the softener.
Water supply maximum hardness (gpg)*
110
Water supply maximum clear water iron (ppm)*
8
Water pressure limits (min-max psi)
20–125
Water temperature maximum (°F.)
120
Water supply minimum flow rate (gpm)
3
*Determined by water analysis from a qualified water testing laboratory.
44”
36-1/4”
14”
35”
24”
3-3/8”
11-1/2”
INLET - OUTLET
INLET
OUT
