REVERSING THE DOOR SWING
(on some models)
Slide back the top just enough to have access to
the screws.
Remove the top screw and door pin. Reinstall
them on the other side.
Replace the top and three screws.
Place the door in position on the top door pin.
Replace the plug button on the other side of
the door.
TO CHANGE THE DOOR SWING DIRECTION
Carefully set the refrigerator on its left side.
Remove the leveling leg below the bottom hinge
and the leveling leg at the opposite corner.
Remove the bottom hinge. Set the door aside.
Remove the two screws from the other side of
the case bottom.
Remove the three screws that hold the top
in place.
Leveling Legs
Washer
Bottom Hinge
Bottom Hinge
7
(continued next page)
Washer
On some models
the foam slides
back with the top.
Other models
have a piece of
foam with cut-
outs for access
to the screws.
To Next Page
