21
Using
the Master
Light switch
This feature turns off the lights in the fresh
food and freezer compartments.
The switch is located behind the grille panel
at the top of the refrigerator. Lift up the panel
to access the switch.
The switch is located
behind the grille panel.
Type 1 bulb
replacement
NOTE: Before replacing the bulbs, review
the light bulb information and WARNING.
Replacing Type 1 bulbs located in lamps
behind the top pan in the fresh food
compartment and the bottom freezer basket
in the freezer compartment:
1. Set the Master Light switch to the OFF
position (see Using the Master Light switch)
and allow the lamps to cool.
2. To access the lamps in the fresh food
compartment, remove the Humidity Control
pan. See Drawer and Pan Removal section.
Raise the lid of the pan up to expose the
light cover.
2. To access the lamps in the freezer
compartment, remove the bottom freezer
basket. See Freezer Baskets section.
3. On the back wall there is a curved light
shield. Grasp each end of the light shield.
Pull the shield toward you and the tabs
on the shield will release from the slots in
the housing.
4. Remove the glass above the bulbs by pulling
it straight out.
NOTE: Always follow bulb manufacturer’s
directions for handling and replacing bulbs.
5. Remove the bulb by holding the base and
pulling straight up. Replace with a new bulb.
6. Replace the glass by sliding it into place.
Then replace the light shield by resting the
top lip of the shield on top of the light
housing. Then press the sides until the tabs
pop into the slots in the housing.
WARNING – The light shield must
be replaced or the heat from the bulb could
damage the refrigerator.
AVERTISSEMENT :
Vous devez remettre en place l’écran à lumière
pour ne pas endommager votre réfrigérateur
avec la chaleur produite par l’ampoule.
7. Reset the Master Light switch to the ON
position.
Light Shield
Care and Cleaning
Built-In Refrigerators
