GE SunSmart 15079 User Manual

 
  Digital Timer
Models: 15042, 15089, and 15079
Install Set Up:
1. Ifthetimescreeniscompletelyblankitwillneedtobepluggedintoanoutlet
beforeprogrammingcanbegin.Ifthescreenisdisplayingnumbers,itcanbe
programmedandpluggedintothewallafterwards.
2. Beforeprogramming,allsettingsshouldbereset.Theresetbuttonislocated
justbelowthe“HOUR”buttonandisidentiedbyan“R”.Useapaperclipor
ballpointpentopushthe“R”button.Oncepushedthescreenwillshowthe
displaybelowonthescreen.See Diagram A
Diagram A After few seconds

Current Time Setting:
1. Keepthe“CLOCK”buttonpressedduringtheentiresettingoperation.
2. Pressthe“HOUR”buttontosetthehours.
3. Pressthe“MIN”buttontosettheminutes.
4. Pressthe“DAY”buttontoselectthecorrectdayoftheweek.
5. Releasethe“CLOCK”button.Thetimewillnowbeset!
Programming the On/Off Times:
1. Pressthe“SET”buttononce.DiagramBshouldappear.
2. 1ON--:--Shouldbetherstsetting.Thereareatotalof20On/Offsettings.


Diagram B
3. Pressthe“HOUR”andMIN”buttonstosettheONtime.
4. Pressthe“DAY”buttontoselecttheday(s)thatthissettingisrelevant.
5. Pressthe“SET”buttontosaveandproceedtothe1OFF--:--screen.
6. Repeatsteps3,4,and5tosettheOFFtime.Pressingthe“SET”buttonagain
willtakeyouthroughtheother19ON/OFFsettings.
Multiple Weekday Switching Groups:
Apartfromindividualweekdays,pressingthe“DAY”buttonalsoselectsmultiple
daycombinationssuchas:
‧MondaythruFriday ‧Tuesday&Thursday&Saturday
‧Saturday&Sunday‧MondaythruWednesday.
‧MondaythruSaturday‧ThursdaythruSaturday.
‧Monday&Wednesday&Friday‧MondaythruSunday.
Afterselectingaparticulardaycombination,theON/OFFselectionwillbein
effectonthedaycongurationselectedfromabove.
Restart Button:
1. Pressthe“SET”buttontoselecttheON/OFFsettingthatneedstobechanged
2. Pressthe“
”buttontoresetthecurrentON/OFFsettingseeninDiagramC
withouthavingtoscrollthroughallthehours.
Diagram C Current time display
Switching Mode Indication:
Theactualmodeisshowninthedisplayas“ON”,“AUTOON”,“OFF”or
“AUTOOFF”togetherwiththetimeofday.Usethe“MANUAL”buttontoadjust
thistothedesiredsetting.Thiscanbeusedtooverridethetimerasexplained
below.
Manual Override Option:
Independentoftheprogramming,itispossibleatanygiventimetoadvanceto
thenextswitchingcommandbycontinuouslypressingthekey“MANUAL”,as
shownbelow:

 ON=AlwaysON;
 OFF=AlwaysOFF;
 AUTOON=TimerisONandON/OFFprogramisactivated.
 AUTOOFF=TimerisOFFandON/OFFprogramisactivated.
Programming the Countdown Feature:
1. Pressthe“SET”buttonrepeatedlyuntiltheCTDiconappearsonthedisplay.
RefertoDiagramD
2. Pressthe“HOUR”,“MIN”buttonstosettheamountoftimedesiredforthe
devicetobeonbeforeturningoff.
3. Pressthe“CLOCK”buttontostorethesettingandreturntothemaindisplay.
Diagram D
Activating the Countdown Feature:
1. Pressthe“HOUR”and“MIN”buttonsimultaneouslytoactivatethe
countdownfeature.RefertoDiagramEformoredetails
2. OtherFeaturesoftheCountdown
a. Pressthe“MANUAL”buttontopauseorcontinuethecountdown.
b. Pressthe“CLOCK”buttontoswitchbetweentheclockandcountdown
display.
c. Press“HOUR”and“MIN”buttonsimultaneouslytodeactivatethe
countdown.
Diagram E
  
Random, ON/OFF Setting:
1. Pressthe“HOUR”buttonfor3secondstoactivatetherandomfeature.The
displaywillshowtheRNDicon.SeeDiagramF.
2. Pressthe“HOUR”buttonfor3secondstodeactivatetherandomfeature.The
displaywillnotshowtheRNDicon.
Diagram F
Summer Time Feature (DST):
Pushthe“CLOCK”buttonfor3secondstoadvancethecurrenttime1hour,+1h
iconshouldappearonthedisplay.Repeatingthisprocesswilldecreasethetime
by1hourandthe+1hiconwilldisappear.RefertoDiagramG
Diagram G
Power Back Up Feature:
Intheeventofapowerfailure,thetimerwillretainitssettingsforanestimated3
monthsassumingthepowerbackupisfullycharged.
HOUR + MIN
HOUR + MIN
MANUAL
CLOCK
Hour
Current time display
End of countdown ON
Countdown pause
Show current time
Clock
OFFAUTO ONONAUTO OFF
If your Timer looks like this,
use the following instructions
If your Timer does not look like
this, go to the previous page

GE SunSmart 15079 Specifications

General

Programmable	Yes
SunSmart Technology	Yes
Random Vacation Setting	Yes
Battery Backup	Yes
Number of Outlets	1
Voltage	120V
Amperage	15A
Power	1800W
Type	Digital Timer
Electrical Ratings	120VAC, 60Hz
Features	Battery Backup
