GEA Mechanical Equipment / GEA Westfalia Separator Group
Instruction manual
Designation
Mineral oil centrifuge with self-cleaning bowl
Type
OSE 20-0136-067
No.
2064-9001-001
Edition
1010

Table of Contents

Questions and Answers

  • N
    Natalie BooneAug 6, 2025
    Why GEA OSE 20-0136-067 Cleaning Equipment bowl does not come up to rated speed?
    • J
      Janice CarlsonAug 6, 2025
      The bowl may not reach the rated speed due to several reasons. It could be that oil has run down the spindle onto the drive belt, causing it to slip. The motor might be incorrectly connected. There might be an insufficient number of clutch shoes, or they may not be evenly spaced. The drive belt could be stretched or incorrectly fitted. Also, liquid or dirt in the upper frame section could be braking the bowl. To resolve this, clean the belt contact surface of the spindle and clutch pulley, and replace the drive belt if necessary. Check the motor connection and increase the number of clutch shoes, ensuring they are evenly spaced. Verify the drive belt's position and check the operating water discharge, cleaning the inside of the upper frame section.
  • B
    bakerrobertAug 12, 2025
    What to do if GEA OSE 20-0136-067 Cleaning Equipment bowl speed drops during operation?
    • S
      Sarah SosaAug 13, 2025
      If the bowl speed drops during operation, it could be due to oily friction surfaces on the clutch shoes. Wipe these surfaces dry, but avoid using benzene, trichlorethylene, or any other solvent. Another cause might be a stretched drive belt, in which case you should replace it. Lastly, the motor speed itself may be dropping; check the motor and line voltage to ensure they are correct.
  • B
    buchananmeganAug 21, 2025
    How to fix uneven run of GEA Cleaning Equipment centrifuge?
    • K
      Kimberly WalkerAug 21, 2025
      An uneven run of the centrifuge can occur if the bowl is out of balance. This imbalance can be caused by uneven dirt deposits, incorrect bowl assembly, interchanged parts from different bowls, slackened disk stack tension (check if the bowl top is screwed on to the O mark alignment and if there are enough disks), or damaged bowl parts. Another cause could be worn ball bearings. If the bowl is out of balance, shut down the separator, and close the product feed and discharge. Completely open the water supply if the bowl leaks. Replace damaged bearings, using only the ball bearings specified in the parts list.
  • J
    John NguyenAug 28, 2025
    Why GEA OSE 20-0136-067 Cleaning Equipment bowl reaches rated speed too fast?
    • D
      Dr. Julie Robinson MDAug 28, 2025
      If the bowl reaches the rated speed too quickly, it may be due to using too many clutch shoes. Reduce the number of clutch shoes and ensure they are evenly spaced.

Summary

Safety Precautions

Correct Usage

Describes the intended applications and design parameters of the centrifugal separator.

Non-compliance with the Intended Use

Details conditions and personnel restrictions that constitute non-compliant operation.

Safety Markings

Explains the types and importance of safety markings on the separator and control system.

Basic Operating Principles

Explains the fundamental principles of centrifugal separation and bowl speed effects.

Operations on the Separator

Outlines general operational guidelines and demands on personnel.

Maintenance and Repair

Discusses maintenance factors and the importance of timely upkeep.

Corrosion

Details types of corrosion affecting stainless steel bowl material and their implications.

Erosion

Explains erosion caused by solid particles and factors favoring its occurrence.

The Health Hazards Involved When Handling Heavy Oils and Lube Oils

Covers health risks associated with handling heavy oils and lube oils.

Machine Description

Standard Dimensioned Drawing of the Separator

Provides detailed mechanical drawings with dimensions and connection points.

Section Through Separator

Illustrates a cross-sectional view of the separator's internal components.

General

Introduces the separator as a high-speed centrifugal unit with a self-cleaning bowl.

OSE...-0136-...

Describes the OSE separator model with unitrolplus-System and its application.

Main Components of the Separator

Lists and describes the primary components of the separator with their functions.

Supervisory Equipment

Explains the monitoring and control systems, including pressure transmitters and water detectors.

Product Feed Line and Product Discharge Line

Details the lines for product input and output, including throughput monitoring.

Technical Data

Provides detailed specifications for the separator's components and operating parameters.

Operation

Technical Information

Covers separating with the unitrolplus system and bowl ejection.

Before Start-up

Lists essential checks and preparations before initial or post-maintenance startup.

Starting the Separator

Details the procedure for starting the separator motor and feed pump.

Monitoring of Operation

Outlines regular checks and attention points during daily operation.

Setting the Separation Time

Explains how to set the separation time based on throughput and solids loading.

Ejecting the Bowl

Describes automatic and manual procedures for bowl ejection.

Shutting Down the Separator

Details automatic and manual shutdown procedures, including emergency-off.

Trouble Shooting

Provides tables to help locate and eliminate common operational faults.

Installation - Maintenance - Repair

Installation of the Separator

Covers general installation guidelines and dimensioned drawings.

Fitting Orifice Plates, Flow Indicator, Pressure Transmitter

Details the installation of these components for throughput monitoring.

Maintenance and Lubrication

Emphasizes special care during maintenance and outlines the maintenance schedule.

Bowl

Provides an exploded view and parts list for the bowl assembly.

Closing the Hood

Details the procedure for closing the separator hood after maintenance.

Drive

Shows an exploded view of the drive assembly and its components.

Height Adjustment

Explains the importance and procedure for bowl height and pump clearance adjustment.

Final Checks After Assembling the Separator

Lists checks required after assembly and before starting.

Before Long-Term Shut-down of the Separator

Outlines procedures for preparing the separator for extended periods of non-operation.

Storage

Provides guidelines for proper storage of the separator and its components.

Before Restarting

Details checks and procedures required before restarting the separator.

Disposal

Covers the responsible disposal of separator components and materials.

Standard Tools

Lists commonly used tools for operation and maintenance.

Special Tools

Lists specialized tools required for specific maintenance tasks.

Spare Parts

Spare Part Requirements

Emphasizes the use of genuine parts and the risks of non-genuine parts.

Guide to Ordering Spare Parts

Explains the necessary information required for ordering spare parts correctly.
