Geberit
Inlet Valves
1
112
30
243
212
48
G 1/2”
49
170.360.00.1 Diaphragm and lever
IMPULS380 INLET VALVE 1/2”
Art. No. 222.012.00.1
The Geberit Impuls380 cistern inlet valve Art. No. 222.012.00.1 with 1/2” nipple is used in some Geberit cisterns or as a general 1/2” inlet
valve. The Impuls380 cistern inlet valve has an operating pressure range from 10 to 1000 kPa (0.1 to 10 bar). The valve is designed for
fast and quiet filling action.
Service and spare parts
Geberit Impuls380 cistern inlet valve is maintenance friendly. In the event of a blockage, the silicone diaphragm and lever part can be
easily removed without tools for cleaning. The spare part is supplied as a kit (diaphragm, insert, cover and lever) in one package.
