GEDA 500Z - General Information

Rack and pinion hoist
Assembly and Operating Manual
7 / 92 BL054 GB Edition 08.2015
1 General Information
1.1 Information about the instruction manual
This operating manual is an essential aid to operating the machine
successfully and hazard-free.
This operating manual contains important instructions on how to
operate the machine safely, correctly and efficiently. Compliance
with these instructions helps to avoid hazards and increases the
reliability and service life of the machine.
The operating manual must be available at the machine at all times
and must be read and applied by every person commissioned to work
on/with the machine, e.g.:
− Operating, fault rectification during work, disposal of operating
materials and auxiliary supplies,
− assembly, maintenance (servicing, general maintenance, repairs)
and/or transport
The structural elements in this operating manual appear as follows
and have the following meaning:
Health and safety symbol
This symbol is found next to all safety instructions where there is a risk
of injury or a fatality. Observe these instructions and be very cautious!

Attention information
This is found at points where special information or instructions and
restrictions regarding damage prevention are given in order to prevent
damage to the equipment.

Note
This is found at points where information is given about using the
machine economically or instructions are given regarding correct
working procedures.
1.2 Information about the machine
Machine model
GEDA

500 Z
Works number:
14830 (400 V)
21900 (230 V 300 kg
21901 (230 V 500 kg))
Year of construction:
Refer to identification plate on the
machine
Documentation version:
04/2015
